| Model | JCEPEP90 | JCEPEP105 | JCEPEP120 | JCEPEP135 | JCEPEP150 | JCEPEP170 | |
|---|---|---|---|---|---|---|---|
| Screw dia. | mm | 90 | 105 | 120 | 135 | 150 | 170 |
| Foaming rate | times | 8-15 | 8-15 | 8-18 | 5-18 | 5-18 | 5-18 |
| Product width | mm | 1150 | 1150 | 1250 | 1350 | 1250 | 1300 |
| Product thickness | mm | 0.5-3 | 0.5-4 | 0.8-5 | 1-6 | 2-7 | 2-8 |
| Output | kg/h | 80 | 100 | 150 | 180 | 200 | 250 |
| Installed power | KW | 58 | 62 | 98 | 138 | 168 | 198 |
| Actual power | KW | 38 | 48 | 68 | 88 | 110 | 130 |
| Dimensions | m | 16×2.2×2.4 | 18×2.2×2.4 | 18×2.2×2.4 | 22×2.2×2.4 | 24×2.2×2.4 | 26×2.2×2.4 |
| Model | JCEPEP180 | JCEPEP200 | JC-EPEP135/180 | JC-EPEP150/200 | JC-EPEP180/200 | |
|---|---|---|---|---|---|---|
| Screw dia. | mm | 180 | 200 | 135/180 | 150/200 | 180/250 |
| Foaming rate | times | 5-18 | 5-18 | 5-25 | 5-25 | 5-25 |
| Product width | mm | 1300 | 1300 | 1500 | 1500 | 1500 |
| Product thickness | mm | 3-10 | 5-12 | 3-14 | 5-16 | 8-18 |
| Output | kg/h | 300 | 350 | 400 | 450 | 500 |
| Installed power | KW | 238 | 268 | 280 | 298 | 320 |
| Actual power | KW | 160 | 180 | 200 | 230 | 250 |
| Dimensions | m | 26×2.2×2.4 | 28×2.2×2.4 | 28×2.2×2.4 | 30×2.2×2.4 | 34×2.2×2.4 |
Note: The above-mentioned data is only for your reference and we keep the rights for modification of the component and machinery structure. The relevant contents involved in equipment purchase should be subject to the contract.
